Beam Whip Antenna with 5m Cable (LTE714)

The Beam LTE714 Whip Antenna is a highly durable and robust antenna and is weatherproof, designed for harsh environments
It is ideal for 4x4 and Utility vehicle installations as the unique antenna has a quick and simple whip removal function for low height environments.

Read more product features

Beam Whip Antenna with 5m Cable Features

KEY FEATURES & BENEFITS

• High gain whip antenna for robust communication even in rural low coverage areas
• Vibration and shock resistant
• Frequency 698-960 / 1710-2170 / 2300-2700 MHz
• Gain 7.5/4.5/5.5 dBi

Beam Whip Antenna with 5m Cable Specifications

PHYSICAL

Colour Black
Material  Flexible PCB
Cable Length (m)  5
Dimensions  mm (L x W x H) inches (L x W x H)
Unit 1210 (L) Radome Ø 15.6-22.5 47.63 (L) Radome Ø 0.61-0.88
Packing Dimensions 1270 x 120 x 40 50 x 4.72 x 1.57
Weight  kg lb
Unit 1.25 2.75
Packing Weight 1.3 2.86

ENVIRONMENTAL

Temperature  Degrees °C  Degrees °F 
Operating and Storage  -40°C + 85°C -40°F to +185°F

SPECIFICATIONS

Frequency (MHz) 698-960 / 1710-2170 / 2300-2700
Gain (V) 7.5/4.5/5.5
Polarization Vertical
Antenna Type Cellular/LTE
V.S.W.R (dB) <2.5:1
Impedance (ohm) 50
Max Input Power (W) 10
Radiation Pattern Omni-Directional

Brochures

Brochure LTE714 Antenna

For more information please download our LTE714 Antenna Brochure.
Download brochure

Visit our support page to download manuals, qsg, firmware upgrades for this product

Product support

Accessories

LTE151

LTE151

Bull Bar Mount
