Beam Mast/Pole/Rail Mount Antenna (RST210)

MSRP $225 USD

The RST210 is an omni-directional passive antenna for easy installation.  Designed for maritime and fixed building applications, the RST210 has a rugged design making it ideal for harsh weather conditions. The RST210 is not suited to land based transport applications.

Read more product features

Beam Mast/Pole/Rail Mount Antenna Features

Key Features & Benefits

• Iridium Approved
• Best suited for Maritime applications
• Designed for tough weather conditions (IP66)
• Mounts on any US-style Mounting Bracket with 1"-14NF threaded stud (not supplied)
• 12-Month Warranty

Beam Mast/Pole/Rail Mount Antenna Specifications

PHYSICAL

Colour White
Material  ASA
Mounting Type Any US-style Mounting Bracket with 1
Dimensions  mm inches
Antenna (D x H) Ø 95 X 150.0 (191.5 mounting base included) Ø 3.7 x 6 (7.5 mounting base included)
Box (L x W x H) 127 x 290 x 102  5 x 11.4 x 4
Weight  kg lb
Antenna  0.87 (inc bracket) 1.9 (inc bracket)
Box  1.01 2.20

ENVIRONMENTAL 

Temperature Degrees °C  Degrees °F 
Operating and Storage  -40 to +70  -40 to +158
IP Rating IP 66

GENERAL 

Antenna  Iridium 
Frequency  1616-1626.5 MHz
Polarization  Right Hand Circular
Axial Ratio  < 6 dB
Impedance  50 Ohms
VSWR  < 1.5
Cable  No cables supplied – see cable accessories

CONNECTORS 

Iridium  TNC-F

Brochures

Brochure RST210 Mast/Pole/Rail Mount Antenna

For more information please download our RST210 Mast/Pole/Rail Mount Antenna Brochure.
Download brochure

Visit our support page to download manuals, qsg, firmware upgrades for this product

Product support
