RST055A UPS Battery Pack - DISCONTINUED (RST055A)
MSRP $375 (USD) USD
The BEAM RST055A is an industrial grade, compact, high powered, high quality UPS battery backup solution for a range of solutions. It can be sued standalone to charge Satellite handsets, smartphones or power other devices or it can be integrated as part of an overall solution using any of the Beam terminals or docking stations.
- Charging
- USB
- Power
RST055A UPS Battery Pack - DISCONTINUED Features
A Powerful Battery Pack
Key Benefits and Features
• Robust portable mechanical design with aluminium enclosure
• Backup power to Iridium 9555/9575 Extreme phone, BEAM Terminals/Accessories & most USB chargeable devices including smartphones and tablets
• Push button remaining battery LEDs
• Power devices whilst charging
• Over-current protection
• Powered directly from a vehicle 9-32VDC Input or AC Plug Pack.
• 6 month warranty
The Beam RST055A UPS Battery is a powerful battery charger that supplies power to most Beam Products requiring a 5V ot 15V input power and most USB powered portable devices.
The Beam UPS Battery Pack provides backup power to Iridium handsets, Inmarsat handsets, Beam Terminals as well as most USB chargeable portable devices including smartphones and tablets.
RST055A UPS Battery Pack - DISCONTINUED Specifications
Power Specifications
| Power Input Voltage | 9 - 32 V DC, @ 4-1A |
| Input Connector | 4-Way Molex Micro-Fit |
| Main Output | 5/15V @ 2A Selectable |
| Main Output Connector | 3-Way molex micro-fit |
| USB Output | 5V @ 1A |
| USB Output Connector | USB Type A |
Physical Specifications
| Dimensions | mm | inches |
| Outer Box Dimensions | 330 W x 90 D x 140 H | 12.99 W x 3.54 D x 5.51 H |
| Weight | kg | lbs |
| Box Weight | 1.76 | 3.88 |
Environmental Specifications
| Temperature | Degrees °C | Degrees °F |
| Operating | -20°C to 60°C | -4°F to 140°F |
| Charging | 0°C to 45°C | 32°F to 113°F |
| Storage | 25°C to 60°C | 25°F to 60°F |
| Humidity | <85% RH non-condensing |
Input
| Connector | 4-Way Molex Micro-Fit |
| Voltage | 9-32VDC @ 4-1A |
Output
| USB Connector | USB Type A |
| USB Output | 5V @ 1A |
| Main Connector | 3-Way Molex Micro-Fit |
| Main Output | 5/15V @ 2A Selectable |
Battery Specifications
| Charging time | 4 hours fast charging to 80%, additional 3 hours to 100% |
| Capacity | 115Wh |
| Type | Lithium Ion |
Kit Contents
| 15VDC Power Adaptor (Output) |
| Auto Accessory Input Cable |
| 4-way Molex Output Cable |
| UPS Battery |
| DC Power Cable |
| 110-240V AC Plug Pack 15v DC Out |
| USB Cable |
| Quick Start Guide |
Brochures
Brochure RST055A UPS Battery Pack
Visit our support page to download manuals, qsg, firmware upgrades for this product
