IsatDock2 MARINE Anti-Piracy Solution (ISD2MARINE-DPB)
The Beam IsatDock2 MARINE Anti-Piracy Solution, uses a Beam IsatDock2 dock and an Inmarsat IsatPhone 2 satellite telephone handset to provide a complete bundled installation for an anti-piracy installation allowing emergency communications and SOS message to be sent if under threat.
- RJ11/POTS
- PABX Integration
- Speakerphone
- Privacy Handset
- Tracking
- Docking
- Charging
- Ringer
- Mute
- USB/Data Access
- External IO
- Personal Alert
IsatDock2 MARINE Anti-Piracy Solution Features
Safety First
The Anti-Piracy solution ensures that communication can continue if all power or communication equipment on board a vessel has been cut off or destroyed by pirates.
Using the ISatPhone 2’s GPS system this ensures that the dock can receive pinpoint accuracy using an external GPS antenna and enables tracking and ALERT worldwide. Tracking and Instant ALERT messages can be sent via SMS or email address as required and is all configured through the handset.
Alert messages can be easily activated on the unit or alternatively an additional alert button can be installed throughout the vessel to trigger and alert. Once configured the alert system is and will generate an alert message to the pre-set destination once triggered.
The back-up battery that comes with the package can last up to 20 hours on standby and/or 10 hours of talk time.
Alert messages can be easily activated on the unit or alternatively an additional alert button can be installed throughout the vessel to trigger and alert. Once configured the alert system is and will generate an alert message to the pre-set destination once triggered.
The back-up battery that comes with the package can last up to 20 hours on standby and/or 10 hours of talk time.
Key Features & Benefits
• High quality marine grade design, IP65 rated
• Dedicated Privacy Handset
• Anti-Piracy Covert Antenna
• Bluetooth connectivity, via IsatPhone 2
• RJ11/POTS interface, cable runs up to 600m/2000ft
• Voice, SMS, SBD and Circuit Switched Data capable
• Tracking and SOS (Via the ISatPhone 2 handset)
• USB data interface
• Accessory / Ignition sense
• 10-32V DC power input
• AC Plug pack included 110/240 input
• Supports Active and Passive Inmarsat antennas
• Full certified, Inmarsat, RoHS, CE, IEC60945 (vibration, IP rating, temperature and humidity), AS/EN60950
• 2-year repair or replacement warranty
• Dedicated Privacy Handset
• Anti-Piracy Covert Antenna
• Bluetooth connectivity, via IsatPhone 2
• RJ11/POTS interface, cable runs up to 600m/2000ft
• Voice, SMS, SBD and Circuit Switched Data capable
• Tracking and SOS (Via the ISatPhone 2 handset)
• USB data interface
• Accessory / Ignition sense
• 10-32V DC power input
• AC Plug pack included 110/240 input
• Supports Active and Passive Inmarsat antennas
• Full certified, Inmarsat, RoHS, CE, IEC60945 (vibration, IP rating, temperature and humidity), AS/EN60950
• 2-year repair or replacement warranty
Instant Message & Tracking Features
• Dedicated internal GPS receiver
• Periodic location messages
• SMS, SMS to email
• Location message sent upon button press
• Ignition ON/OFF reporting
• Remote location polling via SMS Instant Message Mode
• Single button press on terminal
• Instant GPS location messages
• Supports external “man down” pendant or button
• Remote clearing of alert via SMS
• Tracking/Instant Message
• Periodic location messages
• SMS, SMS to email
• Location message sent upon button press
• Ignition ON/OFF reporting
• Remote location polling via SMS Instant Message Mode
• Single button press on terminal
• Instant GPS location messages
• Supports external “man down” pendant or button
• Remote clearing of alert via SMS
• Tracking/Instant Message
Watch Beam's Anti-Piracy Solution Video
The Beam Piracy Solution is a complete bundled installation that provides an immediate contact/message under threat with the added ability to be able to make or receive a telephone call from the "safe room" at any time.
The personal Alert message can be triggered via a single button press on the IsatDock2 MARINE.
The IsatDock2 MARINE has an active Privacy Handset for private call use.
The IsatDock2 Marine has an IP54 rating, maritime grade design.
Similar items you may be interested in
The Inmarsat Beam IsatDock2 MARINE basic anti-piracy bundle includes:
IsatDock2 MARINE
Inmarsat Beam Dual Mode Covert Antenna
ISD934 ...
View product
IsatDock2 MARINE Anti-Piracy Solution Specifications
Power Specifications
| Power w/o IsatPhone 2 | 130mA | 1.6W |
| Standby + Charging | 360mA | 4.3W |
| Transmit + Charging | 875mA | 10.5W |
| Sleep Mode | 5mA | 60mW |
| Peak Current | 3.5A | 42W |
IsatDock2 MARINE Physical
| Dimensions | mm | inches |
| Dock | 276L x 208W x 100H | 10.87L x 8.18W x 3.93H |
| Weight | kg | lbs |
| Dock | 1.67 | 3.67 |
IsatDock2 MARINE Environmental
| Temperature | °C | °F |
| Operating Range | -25°C to +55°C | -31°F to +131°F |
| Storage | -35°C to +85°C | -31°F to +185°F |
| Humidity | <= 75% RH |
IsatDock2 MARINE Connectors/Interface
| POTS/RJ11 | RJ11/2-wire, 5REN @ 600m, Adjustable dial, ring, busy tone configured frequency and adaptive impedance. |
| Antenna | TNC-Female |
| GPS Antenna | SMA-Female |
| 10-32 VDC | 4-way microFit (AC/DC adaptor, or DC lead) |
| Privacy Handset Port | RJ9 connector |
| Configuration / Data | USB Micro |
| Speakerphone | In-built speaker/microphone |
| LEDs/Buttons | Status LED, Personal Alert/Track, Mute, Speakerphone, Up and Down |
I/O Alarm/Alert
| Track | In-built - single key press |
| 1 x Alarm Loop | Bare wire - Normally closed loop IN to OUT |
Beam Covert Marine Antenna Physical
| Dimensions | mm | inches |
| Antenna | 249.17H x 149.1dia | 9.81H x 5.87dia |
| Weight | kg | lbs |
| Antenna | 0.86 | 1.91 |
Beam Covert Marine Antenna Connectors
| Inmarsat | SMA-F |
| GPS | SMA-F |
Beam Covert Marine Antenna Environmental
| Temperature | °C | °F |
| Operating | -25°C to +55°C | -13°F to +131°C |
Certifications
| Fully certified |
| Inmarsat type approved |
| RoHS |
| CE |
| EMC |
| IP54 |
| C Tick |
ISD2 Marine Anti-Piracy Kit Contents
| IsatDock2 MARINE |
| Beam Inmarsat Covert Antenna |
| RST060 UPS Battery Pack |
| ISD934 18.5m Active Cable Kit |
| RST955 Beam Alert Button |
| RST996 50m Alert Loop Wire |
RST060 UPS Battery Pack Physical
| Dimensions | mm | inches |
| Dimensions | 147 x 38 x 133 | 5.8 x 1.5 x 5.25 |
| Weight | kg | lbs |
| Unit Weight | 0.8 | 1.9 |
RST060 UPS Battery Pack Environmental
| Temperature | Degrees °C | Degrees °F |
| Operating Usage Temperature | 0°C to -40°C | 32°F to -104°F |
Brochures
Brochure IsatDock2 MARINE
For more information please download our IsatDock2 MARINE Brochure.
Download brochure
BEAM Anti-Piracy Solution for Inmarsat2
For more information please download our BEAM Anti-Piracy Solution for Inmarsat.
Download brochure
Visit our support page to download manuals, qsg, firmware upgrades for this product
