Iridium Beam Aero Patch Antenna TSO Approved - DISCONTINUED (RST719)
The Beam RST719 TSO Aero Approved Iridium patch antenna, is designed for aero applications with C-144 TSO Approval.
Iridium Beam Aero Patch Antenna TSO Approved - DISCONTINUED Features
The antenna is supplied complete with bulkhead mount that enables it to be securely mounted without the connectors being exposed to the environment and fitted with a TNC connector. The RST719 is designed to be low profile and aero dynamic.
Key Features
• Iridium approved
• Designed for harsh environments
• Small and lightweight
• Aluminium alloy casting
• TSO approved C - 144
• Manufactured in the USA
• 12 month repair or replacement warranty
• Designed for harsh environments
• Small and lightweight
• Aluminium alloy casting
• TSO approved C - 144
• Manufactured in the USA
• 12 month repair or replacement warranty
Similar items you may be interested in
The Beam RST704 TSO is an Aero Approved dual mode all in one compact Iridium ...
View product
Iridium Beam Aero Patch Antenna TSO Approved - DISCONTINUED Specifications
General
| Polarization | Right Hand Circular |
| Axial Ratio | 3db Max |
| Impedance | 50 OHMS |
| VSWR | < 2.0 : 1 |
| Altitude | 21,336m/70,000ft |
| TSO Approved | C -144 |
Frequency
| Iridium | 1595 ± 30MHz (-1.5dB band width) |
Environmental
| Temperature | Degrees °C | Degrees °F |
| Operating Temp | -55°C to +85°C | -67°C to 185°C |
Physical
| Colour | White | |
| Finish | Polyurethane | |
| Material | A380 Aluminum Alloy – casting. Ultem 2200 Radome | |
| Dimensions | mm | inches |
| Antenna | 20.83H x 88.9 Dia | 0.82H x 3.50 Dia |
| Weight | kg | lbs |
| Antenna | 0.22 | 0.5 |
Connector
| Iridium | TNC Female |
Brochures
Brochure RST719 Iridium Aeronautical Patch Antenna
For more information please download our RST719 Iridium Aeronautical Patch Antenna Brochure.
Download brochure
Visit our support page to download manuals, qsg, firmware upgrades for this product
Product supportAccessories
